How Voltstair works
Powered stair climbing made simple
The motorized Voltstair helps ascend and descend large, heavy and unwieldy items.

See the powered hand truck in action before reviewing the ascending and descending steps.

Ascending
pf-aaf00bd4--ascent-step-1__PID:76fdcc4f-7444-454a-8fe7-9ef6014f6681

STEP 1

The Approach

With the load secured and the Voltstair’s handlebar and tracks folded out, back it up to the staircase until the tracks are approximately 10” from the bottom stair. Then, pull the handlebar towards you until the tracks are resting on the stairs.

pf-f00bd4e5--ascent-step-2__PID:5e76fdcc-4f74-44a5-8a0f-e79ef6014f66

STEP 2

The Ascent

While applying pressure on the handlebar towards the stairs, press the green button and begin walking backwards up the stairs. The tracks will lock in place automatically if you stop pressing the green button.

pf-0bd4e52d--ascent-step-3__PID:1a5e76fd-cc4f-4444-a54a-0fe79ef6014f

STEP 3

The Platform

When you reach the top of the stairs, continue walking the Voltstair backwards over the top landing until the front wheels have cleared the edge of the top stair. Then tip the Voltstair forwards onto its flat ground wheels.

Descending
pf-d4e52d01--descent-step-1__PID:2a1f1099-2d6a-479e-9e5d-fc69a6b1bcdd

STEP 1

The Approach

With your load secured and the tracks and handlebar folded out, tip the Voltstair back to the approximate angle of the staircase you’re planning to descend. Press the yellow button to rotate the tracks to move down the stairs, as you slowly walk toward the stairs, maintaining the angle of the tracks until they are pressed flush against the stairs.

pf-e52d0170--descent-step-2__PID:542a1f10-992d-4ac7-9e5e-5dfc69a6b1bc

STEP 2

The Descent

Continue to press the yellow button while you walk down the stairs behind the Voltstair, and apply pressure on the handlebar towards the stairs. You should not be pulling back on the weight of the load- let the powered tracks do the heavy lifting and just press down on the handlebars.

pf-2d017060--descent-step-3__PID:2b542a1f-1099-4d6a-879e-5e5dfc69a6b1

STEP 3

The Landing

When the back wheels reach the bottom of the staircase, stop pressing the yellow button, and lean the Voltstair forward onto its flatground wheels. Then push it to the desired destination.
